Credit Card

Sandbox end point URL: https://gateway2-stg.tcbpay.com/apis/{method}

Example: https://gateway2-stg.tcbpay.com/apis/sale.php

Production end point URL: https://gateway2.tcbpay.com/apis/{method}

Sale API

This API is responsible to create a new payment transaction. API is compatible of both encrypted and plain credit card method of transactions.

URL To Call: https://gateway2.tcbpay.com/apis/sale.php
Method of Form Submission: POST

proxynization library:

  • Sandbox: https://gateway2-stg.tcbpay.com/services/proxynization_api.js
  • Production: https://gateway2.tcbpay.com/services/proxynization_api.js
1)Include proxynization_api.js script file. Copy the following lines and paste to your HTML page. This will enable the proxynization functionality within your application.

Example:


                                <script type="text/javascript" src="https://[server-name]/services/proxynization_api.js"></script>


2)Implement the callback function. The callback function will be invoked once the proxynization response is returned from our system. We make a function call which invokes the pre-defined callback function and proxynization response is used as argument.

Example:


                                <script type="text/javascript" >
                                function tcbpayClientCallback(responseCode, responseMessage, proxyNumber){

                                if(responseCode == "A01"){
                                document.getElementById('creditcard_number').value = proxyNumber;
                                document.getElementById("formID").submit();
                                } else{
                                alert(responseMessage);
                                return false;
                                }
                                }
                                </script>


  • 3)Design your payment form and insert a proxynization call within the form's submit action.
  • 3.1)The first parameter can either be the value of credit card number, or it can be the ID of the credit card number field. If the value of the parameter starts with a hashtag (#) symbol, the first parameter is assumed to be the ID of the credit card number field. If a hashtag is not present, the first parameter is assumed to be a credit card number.
  • 3.2)The second parameter is the name of the callback function, that will be called when the proxynization call is completed.

Example:


                                <input type="button" value="submit"  onClick="TCBPayProxynizationAPI.process('#creditcard_number','tcbpayClientCallback');" />



The table describes the request parameters for Sale API.

Variable Name Description Required Expected Values
username TCB Pay Gateway Username Y TCB Pay Gateway Username
api_key TCB Pay Gateway API Key Y TCB Pay Gateway API Key
card_token Get token during Add Card vault API. If you use card token then credit card number, expiry month and expiry year are not required. C XXXXXXXXXXXXXXXXXXXXXXXXX
creditcard_number Credit Card Number upon which Sales to be done. It is not required, if use card token number. C 4111111111111111
expire_month Expiry Month of the Credit Card. It is not required, if use card token number. C 06
expire_year Expiry Year of the Credit Card. It is not required, if use card token number. C 2025
cvv CVV of the Credit Card.
To force CVV as required for every transaction in the account setting then cvv is required otherwise it is optional.
C 123
use_secret_key To encrypt creditcard_number without using proxynization_api.js then set secret key in account setting. Make sure to encrypt credit card numbers with AES 128 bit ECB cipher code. N Y or N (default value N)
Y- encrypt creditcard_number using AES 128 bit ECB cipher mode encryption
amount Amount to be charged Y 133.24
currency Currency of Transaction (Allowed currencies will be determined during the time of merchant registration.) Y USD,EUR,GBP,CAD,AUD,NZD,AED,
DKK,MXN,SEK,CHF
company_name Company Name of the customer N -
first_name First name of Account Holder Y Roberto
last_name Last name of Account Holder Y Diaz
adress Address of the customer N 4446 Green Avenue, Suite 56
city City of the customer N Los Angeles
state State of the customer N CA
country_code Country of the customer(ISO alpha-2) Y US, CN
zip_code Zipcode of the customer Y 94085
phone_number Phone Number of the customer N 408-345-2323
email Email ID of the customer Y test@test.com
email_receipt Send transaction details to specified card holder email N Y or N (default value N) Y- Send email N- Not send
emailReceiptDBAEmail Email Receipt To Merchant DBA Contact Email N Y or N (default value N) Y- Send email N- Not send
memo Memo of transaction N
client_ip Client ip address N 127.0.0.1
custom_field_1 N additional parameter 1
custom_filed_2 N additional parameter 2
source C source=SHOPIFY if using Shopify otherwise it is not required
3ds_redirect_url Redirect to this url after 3D-Secure authentication.
(To process transactions with 3Ds, contact TCB Pay to enable 3DS and set 'Denied Payment Transaction' or 'Continue Payment Transaction' for non 3-D Secure card transactions.)
C if using 3D-Secure then it is require otherwise it is not required.

Response:

Response of the API Call is a JSON array. For Error,Two elements are returned. They are code and description.For Successful transactions, three elements are returned. They are code, description and transaction_id. Response code is always 00 for successful API call.

Example:


                                  <form name="" id="formID" action="https://gateway2.tcbpay.com/apis/sale.php" method="post">
                                  <input type="text" name="username" value="tcbpayusername"/>
                                  <input type="text" name="api_key" value="tcbpayapikey"/>
                                  <input type="text" name="creditcard_number" id="creditcard_number" value="4111111111111111"/>
                                  <input type="text" name="expire_month" value="06"/>
                                  <input type="text" name="expire_year" value="2025"/>
                                  <input type="text" name="cvv" value="123"/>
                                  <input type="text" name="amount" value="14.5"/>
                                  <input type="text" name="currency" value="USD"/>
                                  <input type="text" name="company_name" value="TCB Pay"/>
                                  <input type="text" name="first_name" value="Roberto"/>
                                  <input type="text" name="last_name" value="Diaz"/>
                                  <input type="text" name="address" value="4446 Green Avenue, Suite 56"/>
                                  <input type="text" name="city" value="Los Angeles"/>
                                  <input type="text" name="state" value="CA"/>
                                  <input type="text" name="country_code" value="US"/>
                                  <input type="text" name="zip_code" value="11111"/>
                                  <input type="text" name="phone_number" value="323-323-3223"/>
                                  <input type="text" name="client_ip" value="127.0.0.1"/>
                                  <input type="text" name="email" value="abcdef@mail.com"/>
                                  <input type="checkbox" name="email_receipt"  value="Y"/>
                                  <br/>
                                  <input type="button" value="submit" onClick="TCBPayProxynizationAPI.process('#creditcard_number','tcbpayClientCallback');" />
                                  </form>
                                  <script type="text/javascript" >
                                  function tcbpayClientCallback(responseCode, responseMessage, proxyNumber){

                                  if(responseCode == "A01"){
                                  document.getElementById('creditcard_number').value = proxyNumber;
                                  document.getElementById("formID").submit();
                                  } else{
                                  alert(responseMessage);
                                  return false;
                                  }
                                  }
                                  </script>



Sample Response :

{"response":{"code":"00","description":" Transaction Entry Success","transaction_id":102," total_amount":15.7," convenience_fee":1.2}}

Sample Response for 3D-Secure :

{"response":{"code":"00","description":"Transaction pending cardholder authentication","transaction_id":102,"redirect_url":"https://gateway2.tcbpay.com/challenge_request.php?uid=xxxxxxxxx"}}

Subscriber need to redirect to redirect_url within 30 seconds.

After 3DS challenge API response is redirected to 3ds_redirect_url, parameters are transaction_id, code and description.

Authorize API:

This API is responsible to perform pre-authorization payment. Note: API is compatible of both encrypted and plain credit card method of transactions.

URL To Call: https://gateway2.tcbpay.com/apis/ authorize.php
Method of Form Submission: POST

proxynization library:

  • Sandbox: https://gateway2-stg.tcbpay.com/services/proxynization_api.js
  • Production: https://gateway2.tcbpay.com/services/proxynization_api.js
1)Include proxynization_api.js script file. Copy the following lines and paste to your HTML page. This will enable the proxynization functionality within your application.

Example:


                                <script type="text/javascript" src="https://[server-name]/services/proxynization_api.js"></script>


2)Implement the callback function. The callback function will be invoked once the proxynization response is returned from our system. We make a function call which invokes the pre-defined callback function and proxynization response is used as argument.

Example:


                                function tcbpayClientCallback(responseCode, responseMessage, proxyNumber){

                                if(responseCode == "A01"){
                                document.getElementById('creditcard_number').value = proxyNumber;
                                document.getElementById("formID").submit();
                                } else{
                                alert(responseMessage);
                                return false;
                                }
                                }
                                </script>


  • 3)Design your payment form and insert a proxynization call within the form's submit action.
  • 3.1)The first parameter can either be the value of credit card number, or it can be the ID of the credit card number field. If the value of the parameter starts with a hashtag (#) symbol, the first parameter is assumed to be the ID of the credit card number field. If a hashtag is not present, the first parameter is assumed to be a credit card number.
  • 3.2)The second parameter is the name of the callback function, that will be called when the proxynization call is completed.

Example:


                                <input type="button" value="submit"  onClick="TCBPayProxynizationAPI.process('#creditcard_number','tcbpayClientCallback');" />



The table describes the request parameters for Authorize API.
Variable Name Description Required Expected Values
username TCB Pay Gateway Username Y TCB Pay Gateway Username
api_key TCB Pay Gateway API Key Y TCB Pay Gateway API Key
card_token Get token during Add Card vault API. If you use card token then not required credit card number, expiry month and expiry year. C XXXXXXXXXXXXXXXXXXXXXXXXX
creditcard_number Credit Card Number upon which Sales to be done. It is not required, if use card token number. C 4111111111111111
expire_month Expiry Month of the Credit Card. It is not required, if use card token number. C 06
expire_year Expiry Year of the Credit Card. It is not required, if use card token number. C 2025
cvv CVV of the Credit Card Y 123
amount Amount to be charged Y 133.24
currency Currency of Transaction (Allowed currencies will be determined during the time of merchant registration.) Y USD,EUR,GBP,CAD,AUD,NZD,AED,DKK,MXN,SEK,CHF
company_name Company Name of the customer N -
first_name First name of Account Holder Y Roberto
last_name Last name of Account Holder Y Diaz
adress Address of the customer N 4446 Green Avenue, Suite 56
city City of the customer N Los Angeles
state State of the customer N CA
country_code Country of the customer(ISO alpha-2) Y US, CN
zip_code Zipcode of the customer Y 94085
phone_number Phone Number of the customer N 408-345-2323
email Email ID of the customer Y test@test.com
email_receipt Send transaction details to specified card holder email N Y or N (default value N) Y- Send email N- Not send
emailReceiptDBAEmail Email Receipt To Merchant DBA Contact Email N Y or N (default value N) Y- Send email N- Not send
memo Memo of transaction N
client_ip Client ip address N 127.0.0.1

Response:

Response of the API Call is a JSON array. For Error,Two elements are returned. They are code and description.For Successful transactions, three elements are returned. They are code, description and transaction_id. Response code is always 00 for successful API call.

Example:


                                  <form name="" id="formID" action="https://gateway2.tcbpay.com/apis/authorize.php" method="post">
                                  <input type="text" name="username" value="tcbpayusername"/>
                                  <input type="text" name="api_key" value="tcbpayapikey"/>
                                  <input type="text" name="creditcard_number" id="creditcard_number" value="4111111111111111"/>
                                  <input type="text" name="expire_month" value="06"/>
                                  <input type="text" name="expire_year" value="2025"/>
                                  <input type="text" name="cvv" value="123"/>
                                  <input type="text" name="amount" value="14.5"/>
                                  <input type="text" name="currency" value="USD"/>
                                  <input type="text" name="company_name" value="TCB Pay"/>
                                  <input type="text" name="first_name" value="Roberto"/>
                                  <input type="text" name="last_name" value="Diaz"/>
                                  <input type="text" name="address" value="4446 Green Avenue, Suite 56"/>
                                  <input type="text" name="city" value="Los Angeles"/>
                                  <input type="text" name="state" value="CA"/>
                                  <input type="text" name="country_code" value="US"/>
                                  <input type="text" name="zip_code" value="11111"/>
                                  <input type="text" name="phone_number" value="323-323-3223"/>
                                  <input type="text" name="email" value="abcdef@mail.com"/>
                                  <input type="checkbox" name="email_receipt"  value="Y"/>
                                  <br/>
                                  <input type="button" value="submit" onClick="TCBPayProxynizationAPI.process('#creditcard_number','tcbpayClientCallback');" />
                                  </form>
                                  <script type="text/javascript" >
                                  function tcbpayClientCallback(responseCode, responseMessage, proxyNumber){

                                  if(responseCode == "A01"){
                                  document.getElementById('creditcard_number').value = proxyNumber;
                                  document.getElementById("formID").submit();
                                  } else{
                                  alert(responseMessage);
                                  return false;
                                  }
                                  }
                                  </script>



Sample Response :

{"response":{"code":"01","description":" Merchant Information is Missing"}}

Capture API:

This API is responsible to capture an existing authorization transaction.

URL To Call: https://gateway2.tcbpay.com/apis/ capture.php
Method of Form Submission: POST
The table describes the request parameters for Capture API.
Variable Name Description Required Expected Values
username TCB Pay Gateway Username Y TCB Pay Gateway Username
api_key TCB Pay Gateway API Key Y TCB Pay Gateway API Key
transaction_id Unique transaction id generate by gateway Y -
amount Amount to be charged, <= orginal transaction amount Y 133.24
email_receipt Send transaction details to specified email during authorize N Y or N (default value N) Y- Send email N- Not send

Response:

Response of the API Call is a JSON array. For Error,Two elements are returned. They are code and description.For Successful transactions, three elements are returned. They are code, description and transaction_id. Response code is always 00 for successful API call.

Example:


                                  <form name="" action="https://gateway2.tcbpay.com/apis/capture.php" method="post">
                                  <input type="text" name="username" value=" tcbpayusername"/>
                                  <input type="text" name="api_key" value=" tcbpayapikey"/>
                                  <input type="text" name="transaction_id" value=""/>
                                  <input type="text" name="amount" value="14.5"/>
                                  <input type="checkbox" name="email_receipt"  value="Y"/>
                                  <br/>
                                  <input type="submit" value="submit"/>
                                  </form>



Sample Response :

{"response":{"code":"01","description":" Merchant Information is Missing"}}

Void API:

This API is responsible to cancel an existing transaction.

URL To Call: https://gateway2.tcbpay.com/apis/ void.php
Method of Form Submission : POST
The table describes the request parameters for Void API.
Variable Name Description Required Expected Values
username TCB Pay Gateway Username Y TCB Pay Gateway Username
api_key TCB Pay Gateway API Key Y TCB Pay Gateway API Key
transaction_id Unique transaction id generate by gateway Y -
email_receipt Send transaction details to specified email during authorize N Y or N (default value N) Y- Send email N- Not send

Response:

Response of the API Call is a JSON array. For Error,Two elements are returned. They are code and description.For Successful transactions, three elements are returned. They are code, description and transaction_id. Response code is always 00 for successful API call.

Example:


                                  <form name="" action="https://gateway2.tcbpay.com/apis/void.php" method="post">
                                  <input type="text" name="username" value=" tcbpayusername"/>
                                  <input type="text" name="api_key" value=" tcbpayapikey"/>
                                  <input type="text" name="transaction_id" value=""/>
                                  <input type="checkbox" name="email_receipt"  value="Y"/>
                                  <br/>
                                  <input type="submit" value="submit"/>
                                  </form>



Sample Response :

{"response":{"code":"01","description":" Merchant Information is Missing"}}

Refund API:

This API is responsible to refund an existing successful transaction.

URL To Call: https://gateway2.tcbpay.com/apis/ refund.php
Method of Form Submission : POST
The table describes the request parameters for Refund API.
Variable Name Description Required Expected Values
username TCB Pay Gateway Username Y TCB Pay Gateway Username
api_key TCB Pay Gateway API Key Y TCB Pay Gateway API Key
transaction_id Unique transaction id generate by gateway Y -
amount Amount to be charged, <= orginal transaction amount Y 133.24
email_receipt Send transaction details to specified email during authorize N Y or N (default value N) Y- Send email N- Not send

Response:

Response of the API Call is a JSON array. For Error,Two elements are returned. They are code and description.For Successful transactions, three elements are returned. They are code, description and transaction_id. Response code is always 00 for successful API call.

Example :


                                  <form name="" action="https://gateway2.tcbpay.com/apis/refund.php" method="post">
                                  <input type="text" name="username" value=" tcbpayusername"/>
                                  <input type="text" name="api_key" value=" tcbpayapikey"/>
                                  <input type="text" name="transaction_id" value=""/>
                                  <input type="text" name="amount" value="14.5"/>
                                  <input type="checkbox" name="email_receipt"  value="Y"/>
                                  <br/>
                                  <input type="submit" value="submit"/>
                                  </form>



Sample Response :

{"response":{"code":"01","description":" Merchant Information is Missing"}}

Unreference Refund API

This API is responsible to create a new payment transaction. API is compatible of both encrypted and plain credit card method of transactions.

URL To Call: https://gateway2.tcbpay.com/apis/unreference_refund.php
Method of Form Submission: POST

proxynization library:

  • Sandbox: https://gateway2-stg.tcbpay.com/services/proxynization_api.js
  • Production: https://gateway2.tcbpay.com/services/proxynization_api.js
1)Include proxynization_api.js script file. Copy the following lines and paste to your HTML page. This will enable the proxynization functionality within your application.

Example:


                                <script type="text/javascript" src="https://[server-name]/services/proxynization_api.js"></script>


2)Implement the callback function. The callback function will be invoked once the proxynization response is returned from our system. We make a function call which invokes the pre-defined callback function and proxynization response is used as argument.

Example:


                                <script type="text/javascript" >
                                function tcbpayClientCallback(responseCode, responseMessage, proxyNumber){

                                if(responseCode == "A01"){
                                document.getElementById('creditcard_number').value = proxyNumber;
                                document.getElementById("formID").submit();
                                } else{
                                alert(responseMessage);
                                return false;
                                }
                                }
                                </script>


  • 3)Design your payment form and insert a proxynization call within the form's submit action.
  • 3.1)The first parameter can either be the value of credit card number, or it can be the ID of the credit card number field. If the value of the parameter starts with a hashtag (#) symbol, the first parameter is assumed to be the ID of the credit card number field. If a hashtag is not present, the first parameter is assumed to be a credit card number.
  • 3.2)The second parameter is the name of the callback function, that will be called when the proxynization call is completed.

Example:


                                <input type="button" value="submit"  onClick="TCBPayProxynizationAPI.process('#creditcard_number','tcbpayClientCallback');" />



The table describes the request parameters for Unreference Refund API

Variable Name Description Required Expected Values
username TCB Pay Gateway Username Y TCB Pay Gateway Username
api_key TCB Pay Gateway API Key Y TCB Pay Gateway API Key
creditcard_number Credit Card Number upon which Unreference Refund to be done. It is not required, if use card token number. C 4111111111111111
expire_month Expiry Month of the Credit Card. It is not required, if use card token number. C 06
expire_year Expiry Year of the Credit Card. It is not required, if use card token number. C 2025
use_secret_key To encrypt creditcard_number without using proxynization_api.js then set secret key in account setting. Make sure to encrypt credit card numbers with AES 128 bit ECB cipher code. N Y or N (default value N)
Y- encrypt creditcard_number using AES 128 bit ECB cipher mode encryption
amount Amount to be charged Y 133.24
currency Currency of Transaction (Allowed currencies will be determined during the time of merchant registration.) Y USD,EUR,GBP,CAD,AUD,NZD,AED,
DKK,MXN,SEK,CHF
company_name Company Name of the customer N -
first_name First name of Account Holder Y Roberto
last_name Last name of Account Holder Y Diaz
adress Address of the customer N 4446 Green Avenue, Suite 56
city City of the customer N Los Angeles
state State of the customer N CA
country_code Country of the customer(ISO alpha-2) Y US, CN
zip_code Zipcode of the customer Y 94085
phone_number Phone Number of the customer N 408-345-2323
email Email ID of the customer Y test@test.com
email_receipt Send transaction details to specified card holder email N Y or N (default value N) Y- Send email N- Not send
emailReceiptDBAEmail Email Receipt To Merchant DBA Contact Email N Y or N (default value N) Y- Send email N- Not send
client_ip Client ip address N 127.0.0.1
custom_field_1 N additional parameter 1
custom_filed_2 N additional parameter 2

Response:

Response of the API Call is a JSON array. For Error,Two elements are returned. They are code and description.For Successful transactions, three elements are returned. They are code, description and transaction_id. Response code is always 00 for successful API call.

Example:


                                  <form name="" id="formID" action="https://gateway2.tcbpay.com/apis/unreference_refund.php" method="post">
                                  <input type="text" name="username" value="tcbpayusername"/>
                                  <input type="text" name="api_key" value="tcbpayapikey"/>
                                  <input type="text" name="creditcard_number" id="creditcard_number" value="4111111111111111"/>
                                  <input type="text" name="expire_month" value="06"/>
                                  <input type="text" name="expire_year" value="2025"/>
                                  <input type="text" name="amount" value="4.5"/>
                                  <input type="text" name="currency" value="USD"/>
                                  <input type="text" name="company_name" value="TCB Pay"/>
                                  <input type="text" name="first_name" value="Roberto"/>
                                  <input type="text" name="last_name" value="Diaz"/>
                                  <input type="text" name="address" value="4446 Green Avenue, Suite 56"/>
                                  <input type="text" name="city" value="Los Angeles"/>
                                  <input type="text" name="state" value="CA"/>
                                  <input type="text" name="country_code" value="US"/>
                                  <input type="text" name="zip_code" value="11111"/>
                                  <input type="text" name="phone_number" value="323-323-3223"/>
                                  <input type="text" name="client_ip" value="127.0.0.1"/>
                                  <input type="text" name="email" value="abcdef@mail.com"/>
                                  <input type="checkbox" name="email_receipt"  value="Y"/>
                                  <br/>
                                  <input type="button" value="submit" onClick="TCBPayProxynizationAPI.process('#creditcard_number','tcbpayClientCallback');" />
                                  </form>
                                  <script type="text/javascript" >
                                  function tcbpayClientCallback(responseCode, responseMessage, proxyNumber){

                                  if(responseCode == "A01"){
                                  document.getElementById('creditcard_number').value = proxyNumber;
                                  document.getElementById("formID").submit();
                                  } else{
                                  alert(responseMessage);
                                  return false;
                                  }
                                  }
                                  </script>



Sample Response :

{"response":{"code":"00", "transaction_id":102, "amount":4.5, "description":" Your transaction is approved."}}

Report API:

This API is responsible to generate transaction reports.

URL To Call: https://gateway2.tcbpay.com/apis/report.php
Method of Form Submission : POST
The table describes the request parameters for Report API.
Variable Name Description Required Expected Values
username TCB Pay Gateway Username Y TCB Pay Gateway Username
api_key TCB Pay Gateway API Key Y TCB Pay Gateway API Key
start_date From transaction date Y date format YYYY-MM-DD
end_date To transaction date Y date format YYYY-MM-DD
transaction_type Type of transaction N (default all transaction) SALE,AUTHORIZE,CAPTURE,REFUND,VOID,CREDIT
transaction_status Status of transaction N (default all transaction) SUCCESS,FAIL

Response:

Response of the API Call is a JSON array. For Error,Two elements are returned. They are code and description.For Successful transactions, three elements are returned. They are code, description and array of transactions. Response code is always 00 for successful API call.

Example :


                                  <form name="" action="https://gateway2.tcbpay.com/apis/report.php" method="post">
                                  <input type="text" name="username" value="tcbpayusername"/>
                                  <input type="text" name="api_key" value="tcbpayapikey"/>
                                  <input type="text" name="start_date" value="2021-01-15"/>
                                  <input type="text" name="end_date" value="2021-03-15"/>
                                  <br/>
                                  <input type="submit" value="submit"/>
                                  </form>



Sample Response :

{ "response": { "code": "00", "description": "success", "transactions": [ { "transaction_id": "****************", "parent_transaction_id": "", "transaction_type": "SALE", "transaction_status": "SUCCESS", "transaction_time": "2021-03-12 01:45:20", "time_zone": "---------", "gmt_time": "2021-03-16 06:22:00", "credit_card_number": "************0013", "currency": "USD", "total_amount": "14.5", "amount": "14.5", "surcharge": "0", "tax": "0", "tip": "0", "first_name": "", "last_name": "", "company_name": "", "address_1": "", "address_2": "", "city": "", "state": "", "zip_code": "", "email": "test@test.com", "phone_no": "", "is_risk_hold": "YES", "risk_description": "High Average Ticket vs Contract, Increased Credit Ratio - 90-Day AVG Returns" } ] } }

Response Codes:

Code Description
01 username is missing or invalid
02 Credit card is missing or invalid
03 Expiration Date is missing or invalid
04 First/Last Name is missing
05 Invalid Country Code
06 Proper Customer Email Id is missing
07 Invalid Amount
08 Transaction Currency is Missing
09 api_key is missing or invalid
10 Requested Currency is not allowed for this Merchant
11 Couldn't process transaction due to load balancer rules!!
12 Transaction ID is missing or invalid
13 Refund is not possible,Its already Void
14 Refund is not possible,Its already exceeds Actual Amount
15 Capture is not possible
16 Void is not possible
17 Sale Limit exceeded
18 Monthly Limit exceeded
19 Transaction Limit exceeded
20 IP/Transaction Limit exceeded
21 Slang word not allowed
22 IP Address is missing/invalid
A1 Transaction Entry Failure
A2 Transaction Update Failure
UN Unknown error, Please contact to administrator
F Your transaction is declined
00 Transaction Entry Success

Sandbox:

Sandbox end point URL: https://gateway2-stg.tcbpay.com/apis/{method}
Example: https://gateway2-stg.tcbpay.com/apis/sale.php

Test Credit Card's Details:

Card Number Type of use CVV
4005510000000013 Regular 123
4111111111111111 Regular 111
4012001037141112 Regular 083
5111111111111111 Regular 123
4761739000091011 (success OTP: 0101 , fail OTP: 3333) 3DS 123
5204730000001011 (success OTP: 4445 , fail OTP: 9999) 3DS 123

Vault

Sandbox end point URL: https://gateway2-stg.tcbpay.com/apis/{method}

Example: https://gateway2-stg.tcbpay.com/apis/sale.php

Production end point URL: https://gateway2.tcbpay.com/apis/{method}

Add Card API

This API is responsible to store Card information inside TCB Pay Vault

URL To Call: https://gateway2.tcbpay.com/apis/add-card-vault.php
Method of Form Submission: POST

proxynization library:

  • Sandbox: https://gateway2-stg.tcbpay.com/services/proxynization_api.js
  • Production: https://gateway2.tcbpay.com/services/proxynization_api.js
1)Include proxynization_api.js script file. Copy the following lines and paste to your HTML page. This will enable the proxynization functionality within your application.

Example:


                                <script type="text/javascript" src="https://[server-name]/services/proxynization_api.js"></script>


2)Implement the callback function. The callback function will be invoked once the proxynization response is returned from our system. We make a function call which invokes the pre-defined callback function and proxynization response is used as argument.

Example:


                                <script type="text/javascript" >
                                function tcbpayClientCallback(responseCode, responseMessage, proxyNumber){

                                if(responseCode == "A01"){
                                document.getElementById('creditcard_number').value = proxyNumber;
                                document.getElementById("formID").submit();
                                } else{
                                alert(responseMessage);
                                return false;
                                }
                                }
                                </script>


  • 3)Design your payment form and insert a proxynization call within the form's submit action.
  • 3.1)The first parameter can either be the value of credit card number, or it can be the ID of the credit card number field. If the value of the parameter starts with a hashtag (#) symbol, the first parameter is assumed to be the ID of the credit card number field. If a hashtag is not present, the first parameter is assumed to be a credit card number.
  • 3.2)The second parameter is the name of the callback function, that will be called when the proxynization call is completed.

Example:


                                <input type="button" value="submit"  onClick="TCBPayProxynizationAPI.process('#creditcard_number','tcbpayClientCallback');" />



The table describes the request parameters for Add Card API.

Variable Name Description Required Expected Values
username TCB Pay Gateway Username Y TCB Pay Gateway Username
api_key TCB Pay Gateway API Key Y TCB Pay Gateway API Key
creditcard_number Credit Card Number Y 4111111111111111
expiry_month Expiry Month of the Credit Card Y 06
expiry_year Expiry Year of the Credit Card Y 2025
card_holder_name Card holder name of the Credit Card Y Roberto Diaz

Response:

Response of the API Call is a JSON array. For Error,Two elements are returned. They are code and description.For Successful transactions, three elements are returned. They are code, description and token. Response code is always 00 for successful API call.

Example:


                                  <form name="" id="formID" action="https://gateway2.tcbpay.com/apis/add-card-vault.php" method="post">
                                  <input type="text" name="username" value=" tcbpayusername"/>
                                  <input type="text" name="api_key" value=" tcbpayapikey"/>
                                  <input type="text" name="creditcard_number" id="creditcard_number" value="4111111111111111"/>
                                  <input type="text" name="expiry_month" value="06"/>
                                  <input type="text" name="expiry_year" value="2025"/>
                                  <input type="text" name="card_holder_name" value="Roberto Diaz"/>
                                  <br/>
                                  <input type="button" value="submit" onClick="TCBPayProxynizationAPI.process('#creditcard_number','tcbpayClientCallback');" />
                                  </form>
                                  <script type="text/javascript" >
                                  function tcbpayClientCallback(responseCode, responseMessage, proxyNumber){

                                    if(responseCode == "A01"){
                                      document.getElementById('creditcard_number').value = proxyNumber;
                                      document.getElementById("formID").submit();
                                    } else{
                                      alert(responseMessage);
                                      return false;
                                    }
                                  }
                                  </script>



Sample Response :

{"response":{"code":"00","description":"Card is successfully added to vault","token":XXXXXXXXXXXXXXXXXXXXXXXXX}}

Card Details API:

This API is responsible to retrieve card details from Vault.

URL To Call: https://gateway2.tcbpay.com/apis/ get-card-details.php
Method of Form Submission: POST
The table describes the request parameters for Card Details API.
Variable Name Description Required Expected Values
username TCB Pay Gateway Username Y TCB Pay Gateway Username
api_key TCB Pay Gateway API Key Y TCB Pay Gateway API Key
token Unique token number, get it during creating new card vault Y XXXXXXXXXXXXXXXXXXXXXXXXX

Response:

Response of the API Call is a JSON array. For Error,Two elements are returned. They are code and description.For Successful transactions, three elements are returned. They are code, description and details. Response code is always 00 for successful API call.

Example:


                                  <form name="" id="formID" action="https://gateway2.tcbpay.com/apis/get-card-details.php" method="post">
                                    <input type="text" name="username" value=" tcbpayusername"/>
                                    <input type="text" name="api_key" value=" tcbpayapikey"/>
                                    <input type="text" name="token" value="XXXXXXXXXXXXXXXXXXXXXXXXX"/>
                                    <br/>
                                    <input type="submit" value="submit"/>
                                  </form>



Sample Response :

{ "response": { "code": "00", "description": "success", "details": { "token": "XXXXXXXXXXXXXXXXXXXXXXXXX", "card_holder_name": "Test card holder name", "creditcard_number": "400551******0013", "expiry_month": "06", "expiry_year": "2025" } } }

Delete Card API:

This API is responsible to delete secure card details from Vault.

URL To Call: https://gateway2.tcbpay.com/apis/ delete-card-vault.php
Method of Form Submission : POST
The table describes the request parameters for Delete Card API.
Variable Name Description Required Expected Values
username TCB Pay Gateway Username Y TCB Pay Gateway Username
api_key TCB Pay Gateway API Key Y TCB Pay Gateway API Key
token Unique token number, get it during creating new card vault Y XXXXXXXXXXXXXXXXXXXXXXXXX

Response:

Response of the API Call is a JSON array. For Error,Two elements are returned. They are code and description.For Successful transactions, three elements are returned. They are code, description and token. Response code is always 00 for successful API call.

Example:


                                  <form name="" action="https://gateway2.tcbpay.com/apis/delete-card-vault.php" method="post">
                                  <input type="text" name="username" value=" tcbpayusername"/>
                                  <input type="text" name="api_key" value=" tcbpayapikey"/>
                                  <input type="text" name="token" value=""/>
                                  <br/>
                                  <input type="submit" value="submit"/>
                                  </form>



Sample Response :

{"response":{"code":"00","description":"Card Vault is successfully deleted","token":"XXXXXXXXXXXXXXXXXXXXXXXXX"}}

Sale API

This API is responsible to create a new payment transaction.

URL To Call: https://gateway2.tcbpay.com/apis/sale.php
Method of Form Submission: POST

The table describes the request parameters for Sale API.

Variable Name Description Required Expected Values
username TCB Pay Gateway Username Y TCB Pay Gateway Username
api_key TCB Pay Gateway API Key Y TCB Pay Gateway API Key
card_token Get token during Add Card vault API. Y XXXXXXXXXXXXXXXXXXXXXXXXX
cvv CVV of the Credit Card Y 123
amount Amount to be charged Y 133.24
currency Currency of Transaction (Allowed currencies will be determined during the time of merchant registration.) Y USD,EUR,GBP,CAD,AUD,NZD,
AED,DKK,MXN,SEK,CHF
company_name Company Name of the customer N -
first_name First name of Account Holder Y Roberto
last_name Last name of Account Holder Y Diaz
adress Address of the customer N 4446 Green Avenue, Suite 56
city City of the customer N Los Angeles
state State of the customer N CA
country_code Country of the customer(ISO alpha-2) Y US, CN
zip_code Zipcode of the customer Y 94085
phone_number Phone Number of the customer N 408-345-2323
email Email ID of the customer Y test@test.com
email_receipt Send transaction details to specified email N Y or N (default value N)
Y- Send email
N- Not send
client_ip Client ip address N 127.0.0.1
custom_field_1 N additional parameter 1
custom_filed_2 N additional parameter 2
source C source=SHOPIFY if using Shopify otherwise it is not required

Response:

Response of the API Call is a JSON array. For Error,Two elements are returned. They are code and description.For Successful transactions, three elements are returned. They are code, description and transaction_id, total_amount, convenience_fee. Response code is always 00 for successful API call.

Example:


                                  <form name="" id="formID" action="https://gateway2.tcbpay.com/apis/sale.php" method="post">
                                    <input type="text" name="username" value=" tcbpayusername"/>
                                    <input type="text" name="api_key" value=" tcbpayapikey"/>
                                    <input type="text" name="card_token" id="card_token" value="XXXXXXXXXXXXXXXXXXXXXXXXX"/>
                                    <input type="text" name="cvv" value="123"/>
                                    <input type="text" name="amount" value="14.5"/>
                                    <input type="text" name="currency" value="USD"/>
                                    <input type="text" name="company_name" value="TCB Pay"/>
                                    <input type="text" name="first_name" value="Roberto"/>
                                    <input type="text" name="last_name" value="Diaz"/>
                                    <input type="text" name="address" value="4446 Green Avenue, Suite 56"/>
                                    <input type="text" name="city" value="Los Angeles"/>
                                    <input type="text" name="state" value="CA"/>
                                    <input type="text" name="country_code" value="US"/>
                                    <input type="text" name="zip_code" value="11111"/>
                                    <input type="text" name="phone_number" value="323-323-3223"/>
                                    <input type="text" name="client_ip" value="127.0.0.1"/>
                                    <input type="text" name="email" value="abcdef@mail.com"/>
                                    <input type="checkbox" name="email_receipt"  value="Y"/>
                                    <br/>
                                    <input type="button" value="submit"  />
                                  </form>



Sample Response :

{"response":{"code":"00","description":" Transaction Entry Success","transaction_id":102," total_amount":15.7," convenience_fee":1.2}}

Authorize API:

This API is responsible to perform pre-authorization payment

URL To Call: https://gateway2.tcbpay.com/apis/ authorize.php
Method of Form Submission: POST
The table describes the request parameters for Authorize API.
Variable Name Description Required Expected Values
username TCB Pay Gateway Username Y TCB Pay Gateway Username
api_key TCB Pay Gateway API Key Y TCB Pay Gateway API Key
card_token Get token during Add Card vault API. C XXXXXXXXXXXXXXXXXXXXXXXXX
cvv CVV of the Credit Card Y 123
amount Amount to be charged Y 133.24
currency Currency of Transaction (Allowed currencies will be determined during the time of merchant registration.) Y USD,EUR,GBP,CAD,AUD,NZD,
AED,DKK,MXN,SEK,CHF
company_name Company Name of the customer N -
first_name First name of Account Holder Y Roberto
last_name Last name of Account Holder Y Diaz
adress Address of the customer N 4446 Green Avenue, Suite 56
city City of the customer N Los Angeles
state State of the customer N CA
country_code Country of the customer(ISO alpha-2) Y US, CN
zip_code Zipcode of the customer Y 94085
phone_number Phone Number of the customer N 408-345-2323
e-mail Email ID of the customer Y test@test.com
e-mail receipt Send transaction details to specified email N Y or N (default value N)
Y- Send email
N- Not send
client_ip Client ip address N 127.0.0.1

Response:

Response of the API Call is a JSON array. For Error,Two elements are returned. They are code and description.For Successful transactions, three elements are returned. They are code, description and transaction_id. Response code is always 00 for successful API call.

Example:


                                  <form name="" id="formID" action="https://gateway2.tcbpay.com/apis/authorize.php" method="post">
                                    <input type="text" name="username" value=" tcbpayusername"/>
                                    <input type="text" name="api_key" value=" tcbpayapikey"/>
                                    <input type="text" name="card_token" id="card_token" value="XXXXXXXXXXXXXXXXXXXXXXXXX"/>
                                    <input type="text" name="cvv" value="123"/>
                                    <input type="text" name="amount" value="14.5"/>
                                    <input type="text" name="currency" value="USD"/>
                                    <input type="text" name="company_name" value="TCB Pay"/>
                                    <input type="text" name="first_name" value="Roberto"/>
                                    <input type="text" name="last_name" value="Diaz"/>
                                    <input type="text" name="address" value="4446 Green Avenue, Suite 56"/>
                                    <input type="text" name="city" value="Los Angeles"/>
                                    <input type="text" name="state" value="CA"/>
                                    <input type="text" name="country_code" value="US"/>
                                    <input type="text" name="zip_code" value="11111"/>
                                    <input type="text" name="phone_number" value="323-323-3223"/>
                                    <input type="text" name="email" value="abcdef@mail.com"/>
                                    <input type="checkbox" name="email_receipt"  value="Y"/>
                                    <br/>
                                    <input type="button" value="submit"  />
                                  </form>



Sample Response :

{"response":{"code":"01","description":" Merchant Information is Missing"}}

Response Codes:

Code Description
01 username is missing or invalid
02 Credit card is missing or invalid
03 Expary Month missing or invalid
04 Expary Year missing or invalid
05 Expiry Date is invalid
06 CVV missing or invalid
07 Card Holder Name missing or Credit Card Number missing
08 Token missing
09 api_key is missing or invalid
21 Slang word not allowed
23 Token does not exist
UN Unknown error, Please contact to administrator
F Your transaction is declined
00 Transaction Entry Success

Sandbox:

Sandbox end point URL: https://gateway2-stg.tcbpay.com/apis/{method}
Example: https://gateway2-stg.tcbpay.com/apis/add-card-vault.php

Test Credit Card's Details:

Card Number CVV
4005510000000013 123
4111111111111111 111
4012001037141112 083
5111111111111111 123

ACH

Sandbox end point URL: https://gateway2-stg.tcbpay.com/apis/{method}

Example: https://gateway2-stg.tcbpay.com/apis/sale.php

Production end point URL: https://gateway2.tcbpay.com/apis/{method}

Sale API

This API is responsible to create a new payment transaction. API is compatible of both encrypted and plain credit card method of transactions.

URL To Call: https://gateway2.tcbpay.com/apis/ach_sale.php
Method of Form Submission: POST
The table describes the request parameters for Sale API.
Variable Name Description Required Expected Values
username TCB Pay Gateway Username Y TCB Pay Gateway Username
password TCB Pay Gateway Password Y TCB Pay Gateway Password
currency Currency of Transaction Y USD
account_number Account Number of the customer Y 201534353553
routing_number Routing Number of the customer Y 124343435
bank_name Bank name of check Y Bank of America
amount Amount of the check Y 133.24
account_type Account Type of the customer Y CHECKING, SAVINGS
first_name First name of Account Holder N Roberto
last_name Last name of Account Holder N Diaz
adress Address of the customer N 4446 Green Avenue, Suite 56
city City of the customer N Los Angeles
state State of the customer N CA
country_code Country of the customer N 209 (Follow Country List below)
zip_code Zipcode of the customer N 94085
phone_number Phone Number of the customer N 408-345-2323
e-mail Email ID of the customer N test@test.com
custom_field_1 Custom value 1 N -
custom_filed_2 Custom value 2 N -
custom_filed_3 Custom value 3 N -

Response:

Response Type of the API Call is a JSON array. For Error, Elements are error_code and error_ description and for Successful transactions, Two Elements are returned. success_code, success_description. success_code is always 00.

Example:


                                  <html lang="en">
                                  <head>
                                  <meta charset="UTF-8">
                                  <title>TCB Pay ACH API Test</title>
                                  </head>
                                  <body>
                                  <form name="" action="https://gateway2.tcbpay.com/apis/ach_sale.php" method="post">
                                  <input type="text" name="username" value="tcbpayusername"/>
                                  <input type="text" name="password" value="tcbpaypassword"/>
                                  <input type="text" name="currency" value="USD"/>
                                  <input type="text" name="account_number" value="201534"/>
                                  <input type="text" name="routing_number" value="124343435"/>
                                  <input type="text" name="bank_name" value="Bank of America"/>
                                  <input type="text" name="amount" value="133.24"/>
                                  <input type="text" name="account_type" value="personal"/>
                                  <input type="text" name="first_name" value="Roberto"/>
                                  <input type="text" name="last_name" value="Diaz"/>
                                  <input type="text" name="address" value="4446 Green Avenue, Suite 56"/>
                                  <input type="text" name="city" value="Los Angeles"/>
                                  <input type="text" name="state" value="CA"/>
                                  <input type="text" name="zip_code" value="94085"/>
                                  <input type="text" name="country_code" value="209"/>
                                  <input type="text" name="email" value="test@test.com"/>
                                  <input type="text" name="phone_number" value="408-345-2323"/>
                                  <br/>
                                  <input type="submit" value="submit"/>
                                  </form>
                                  </body>
                                  </html>



Sample Response :

{"response":{"error_code":"03","error_description":"Account Number is Missing or Invalid"}}

Report API:

This API is responsible to generate transaction reports.

URL To Call: https://gateway2.tcbpay.com/apis/merchant_check21_reporting.php
Method of Form Submission : POST
The table describes the request parameters for Report API.
Variable Name Description Required Expected Values
username TCB Pay Gateway Username Y TCB Pay Gateway Username
password TCB Pay Gateway Password Y TCB Pay Gateway Password
start_date From date Y YYYY-MM-DD
end_date To date Y YYYY-MM-DD

Response:

Response Type of the API Call is a JSON array. For Error, Elements are error_code and error_ description and for Successful transactions, Two Elements are returned. success_code, transaction array. success_code is always 00.

Example :


                                  <html lang="en">
                                  <head>
                                  <meta charset="UTF-8">
                                  <title>TCB Pay ACH API Report Test</title>
                                  </head>
                                  <body>
                                  <form name="" action="https://gateway2.tcbpay.com/apis/ merchant_check21_reporting.php"
                                  method="post">
                                  <input type="text" name="username" value="tcbpayusername"/>
                                  <input type="text" name="password" value="tcbpaypassword"/>
                                  <input type="text" name="start_date" value="2019-04-01"/>
                                  <input type="text" name="end_date" value="2019-04-15"/>
                                  <br/>
                                  <input type="submit" value="submit"/>
                                  </form>
                                  </body>
                                  </html>



Sample Response :

{"response":{"error_code":"19","error_description":" Transaction Start Date is missing or invalid"}}

Error Codes:

Error Code Description
01 Merchant Information is Missing
02 Transaction Currency is Missing
03 Account Number is missing or Invalid
04 Routing Number is missing or invalid
05 Check Number is missing or invalid
06 Invalid Amount
07 Account Type is Missing
08 Proper Zipcode is missing
09 Proper Customer Email Id is missing
10 Invalid Processor
11 Requested Currency is not allowed for this Merchant
12 Invalid Merchant Information
13 Invalid Country Code
14 Sale Volume exceeded for this Merchant
15 Monthly Volume exceeded for this Merchant
16 Transaction Limit exceeded for this Merchant
17 IP wise transaction limit exceeded for this Merchant
18 Bank Name is missing
19 Transaction Start Date is missing or invalid
20 Transaction End Date is missing or invalid
A1 Transaction Entry Failure

Country List:

Country Code Country Name
209 United States

Currency List:

Currency Code Currency Name
USD United Sates Dollar

Alternative Payment

Sandbox end point URL: https://gateway2-stg.tcbpay.com/apis/{method}

Example: https://gateway2-stg.tcbpay.com/apis/banktransactions.php

Production end point URL: https://gateway2.tcbpay.com/apis/{method}

Payment API

This API is responsible to a payment request to generate a request token.

URL To Call: https://gateway2.tcbpay.com/apis/banktransactions.php
Method of Form Submission: POST
The table describes the request parameters for Payment API.
Variable Name Description Required Expected Values
username TCB Pay Gateway Username Y TCB Pay Gateway Username
api_key TCB Pay Gateway API Key Y TCB Pay Gateway API Key
currency Currency of Transaction Y USD
amount Amount of the check Y 4.00
first_name First name of Account Holder N Roberto
last_name Last name of Account Holder N Diaz
address Address of the customer N 4446 Green Avenue, Suite 56
phone_number Phone Number of the customer N 408-345-2323
email Email ID of the customer N test@test.com
order_id Order ID of the customer N 1234
return_url After payment transaction user is redirected this url Y URL
callback_url URL to receive transaction details (like code, status, bank_name, transaction_id, order_id). N URL

Response:

Response Type of the API Call is a JSON array. For Error, Elements are code and message and for Successful token creation, Three Elements are returned code, message, redirect_url. code is always 00. We can copy and paste this redirect_url link to another tab or browser for final payment transaction.

Example:


                                  <html lang="en">
                                  <head>
                                  <meta charset="UTF-8">
                                  <title>TCB Pay Alternative Payment API Test</title>
                                  </head>
                                  <body>
                                  <form name="" action="https://gateway2.tcbpay.com/apis/banktransactions.php" method="post">
                                  <input type="text" name="username" value="tcbpayusername"/>
                                  <input type="text" name="api_key" value="tcbpayapikey"/>
                                  <input type="text" name="currency" value="USD"/>
                                  <input type="text" name="amount" value="4.00"/>
                                  <input type="text" name="first_name" value="Roberto"/>
                                  <input type="text" name="last_name" value="Diaz"/>
                                  <input type="text" name="address" value="4446 Green Avenue, Suite 56"/>
                                  <input type="text" name="phone_number" value="408-345-2323"/>
                                  <input type="text" name="email" value="test@test.com"/>
                                  <input type="text" name="order_id" value="1234"/>
                                  <input type="text" name="return_url" value="https://xyz.com/yourpage"/>
                                  <input type="text" name="callback_url" value="https://abc.com/yourpage"/>
                                  <br/>
                                  <input type="submit" value="submit"/>
                                  </form>
                                  </body>
                                  </html>



Sample Response :

{"code":"00","message":"SUCCESS","redirect_url":"https://gateway2-stg.tcbpay.com/apis/bank_payment.php?id=xxxxxxxxxxxxxxxxxxxx"}

Payment report API:

This API is responsible to fetch payment details.

URL To Call: https://gateway2.tcbpay.com/apis/bankaccount_report.php
Method of Form Submission : POST
The table describes the request parameters for Payment report API
Variable Name Description Required Expected Values
username TCB Pay Gateway Username Y TCB Pay Gateway Username
api_key TCB Pay Gateway API Key Y TCB Pay Gateway API Key
start_date Start Date of transaction (Start Date and End Date or Transaction ID) Y YYYY-MM-DD
end_date End Date of transaction (Start Date and End Date or Transaction ID) Y YYYY-MM-DD
transaction_id Unique transaction id generate by gateway (Start Date and End Date or Transaction ID) Y 1234

Response:

Response Type of the API Call is a JSON array. For Error, Elements are error_code and error_description and for Successful transactions, Three Elements are returned. success_code, description, transaction array. success_code is always 00.

Example :


                                  <html lang="en">
                                  <head>
                                  <meta charset="UTF-8">
                                  <title>TCB Pay ACH API Report Test</title>
                                  </head>
                                  <body>
                                  <form name="" action="https://gateway2.tcbpay.com/apis/bankaccount_report.php"
                                  method="post">
                                  <input type="text" name="username" value="tcbpayusername"/>
                                  <input type="text" name="api_key" value="tcbpayapikey"/>
                                  <input type="text" name="start_date" value="2019-04-01"/>
                                  <input type="text" name="end_date" value="2019-04-15"/>
                                  <br/>
                                  <input type="submit" value="submit"/>
                                  </form>
                                  </body>
                                  </html>



Sample Response :

{"response":{"code":"23","description":"Either enter Start Date and End Date or Transaction ID"}}

Error Codes:

Error Code Description
01 username is missing or invalid
09 api_key is missing or invalid
23 Either enter Start Date and End Date or Transaction ID

Sandbox:

Sandbox end point URL: https://gateway2-stg.tcbpay.com/apis/banktransactions.php

Note:

You will get redirect url after calling this api. Then redirect to that url and continue payment process.
Bank name: Bank of America
User ID: thansen59
Password and OTP: Any string value

Merchant Onboarding

Sandbox end point URL: https://app-dev.tcbpay.com/api/{method}

Example: https://app-dev.tcbpay.com/api/onboarding

Production end point URL: https://app.tcbpay.com/api/{method}

Onboarding API

This API is responsible to create a new application.

URL To Call: https://app.tcbpay.com/api/onboarding
Method of Form Submission: POST

The table describes the request parameters for Onboarding API.

Variable Name Description Required Expected Values
username Merchant App Username Y Merchant App Username
password Merchant App Password Y Merchant App Password
legal_name Business Legal Y ABCDEFGH
irs_tax_name Irs Tax Name Y Irs Tax Name
street_number Street number of the Business Address N 777
address Business Address Y 777 Brockton Avenue
address_2 Business Address 2 N Brockton
state State Y MA
city City Y Abington
zip_code Zip Code Y 02351
land_telephone Business Land phone Number Y 4567891120
land_telephone_iso2 Phone number iso extention N +1
ein_no EIN ID Y 654897123 (Should have 9 digits)
started_date Business Start Date Y YYYY-MM-DD
state_filling State of Filing Y MA
business_type Type of Business Owning Y AutoRental, ECommerce, Lodging, MOTO, Restaurant, Retail
is_contact_info_same_as_business_info Is contact info same as business info N Default Y, If N then contact fields should be required
contact_name Contact name Required if is_contact_info_same_as_business_info value N John Paul
contact_title Contact title Required if is_contact_info_same_as_business_info value N CEO, Mr
contact_phone Contact phone Required if is_contact_info_same_as_business_info value N 1800000000
contact_phone_iso2 Contact phone iso extention Required if is_contact_info_same_as_business_info value N +1
contact_email Contact email Required if is_contact_info_same_as_business_info value N 1234@gmail.com
postal_code_extension Zip Code extention N 91
dba_name DBA Name Y ABCDEFGH
street_number Street number of DBA Address Y 777
address DBA Address Y 777 Brockton Avenue
address1 DBA Address 1 N Brockton
city City Y Abington
state State Y MA
zip_code Zip Code Y 02351
phone Phone Number Y 1234567890
business_website Business website Y www.abc.com
dba_business_email Business Email ID Y 1234@gmail.com
add_terminals Add Terminal N Y For Yes, N for No
mail_monthly_merchant_to Mail Monthly merchant to N L-legal,D-dba
ownership_type Ownership Type Y "PublicCorporation", "PrivateCorporation", "SECRegulatedCorporation", "Government", "SoleProprietorship", "LLC", "Partnership", "NonProfit", "FinancialInstitution", "Trust"
zone Customer Service Number N 1 For Business district, 2 for Industrial, 3 for Residential
location Location N 1 for Mall, 2 for Office, 3 for Home, 4 for Shopping area, 5 for Mixed, 6 for Apartment, 7 for Isolated
approx_square_footage Approx Square Footage N 2000
is_all_product_delivered_immediately All product delivered Immediately N Yes, No
is_dba Is DBA N Y: Yes, N: No
dda_type DDA Type Y Checking, Savings
ach_type ACH Type C, Required if DDA Type is Checking CommercialChecking, PrivateChecking
routing_no Bank Routing Number Y 546435745
account_no Bank Account Number Y 123456789456123
batch_close_method Batch Close Method N TimeInitiated, MerchantInitiated
batch_close_time Batch Close Time N 20:00:00
check_for_duplicate_transactions Check For Duplicate Transactions N Yes, No
enable_commercial_card_bin_query Enable Commercial Card Bin Query N Yes, No
swipe_per Swipe Percentage Y If a CNP submission as per MCC selection, default swiped to 0
eco_per Eco Percentage Y --
moto_per Moto Percentage Y --
visa_mc_discover_monthly_volume VISA/DISC./MASTERCARD Monthly Volume $ Y 5000
visa_mc_discover_avg_ticket VISA/DISC./MASTERCARD Average Ticket $ Y 5000
visa_mc_discover_high_ticket High Ticket $ Y 10000000
visa_mc_discover_minimum_ticket Minimum Ticket $ N 1000
amex_monthly_volume AMEX Monthly Volume $ Y 5000
amex_avg_ticket AMEX Average Ticket $ Y 100000
amex_high_ticket High Ticket $ N 1000
amex_minimum_ticket Minimum Ticket $ N 500
card_charge_delay_id Card Charge Delay Y 1 For Same Day, 2 for 1-5 Days, 3 for 6-15 days, 4 for 16-30 days, 5 for over Over 30 Days
type Owner Type C

If ownership type is sole proprietorship:

1. Beneficial Owner1 with firstName, lastName, addressLine1, city, state, country, postalCode, and DOB are mandatory.

2. Other owner attributes are optional. (NOTE: We need to collect dob and SSN (as FederalTaxId) for underwriting the sub-merchant, even though sole proprietorship is exempt.)

3. No other ownership type can be added.

4. A sole proprietorship's sole owner cannot be deleted.


or If ownership type is LLC or Partnership or PrivateCorporation or NonProfit:

1. Control Owner information is Required

2. Beneficial Owner information is Required. When provided, firstName, lastName, addressLine1, city, state, country, and postalCode are mandatory.

2. Beneficial Owner SSN, DOB, and other attributes are optional.

3. They can add up to 10 additional Beneficial Owners (in addition to Control Owner). When provided, firstName, lastName, addressLine1, city, state, country, and postcalCode are mandatory.

"ControlOwner", "BeneficialOwner1", "BeneficialOwner2", "BeneficialOwner3", "BeneficialOwner4", "BeneficialOwner5", "BeneficialOwner6", "BeneficialOwner7", "BeneficialOwner8", "BeneficialOwner9", "BeneficialOwner10"

or:

1. Control Owner information is optional. When provided, firstName, lastName, addressLine1, city, state, country, and postalCode are mandatory.

2. Control Owner SSN, DOB, and other attributes are optional.

3. They can add up to 10 additional Beneficial Owners (in addition to Control Owner). When provided, firstName, lastName, addressLine1, city, state, country, and postcalCode are mandatory.

"ControlOwner", "BeneficialOwner1", "BeneficialOwner2", "BeneficialOwner3", "BeneficialOwner4", "BeneficialOwner5", "BeneficialOwner6", "BeneficialOwner7", "BeneficialOwner8", "BeneficialOwner9", "BeneficialOwner10"
title Owner Title Y Owner, Co-owner, President, Legal Contact, Secretary/Treasurer, Partner, General Manager, Administrator, Vice President, Director, CEO, Corporate Office Title, Principal, CFO, COO
email Email ID Y 1234@gmail.com
first_name First Name Y John
middle_initial Middle Initial N
last_name Last Name Y Paul
date_of_birth Birth Date Y YYYY-MM-DD
street_number Street Number N 777
address Address Y 777 Brockton Avenue
address1 Address 1 N Brockton
city City Y Abington
state State Y MA
zip_code Zip Code Y 02351
postal_code_extension Postal Code Extention N
home_telephone Home Telephone Number Y 1234567890
home_telephone_ext Home Telephone Number Extention N 1234567890
fax_number FAX Number N 1234567890
driving_licance_no Driver Licence No. Y 786fg6587g
driving_licance_state DL issued state N NV
driving_licance_expiration_date DL expiration date N 10-19-2018
driving_licance_issued_city DL issued city N
driving_licance_issued_country DL issued country N
driving_licance_date_issued DL date issued N 10-19-2018
ssn SSN Number Y ASN1234560
has_significant_managerial_control Has significant managerial control N Yes, No
first_gurrantor_name first guarantor Name Y John Paul
first_gurrantor_title first guarantor Title Y CEO
first_gurrantor_date first guarantor Date Y YYYY-MM-DD
second_gurrantor_name Second guarantor Name N John Paul
second_gurrantor_title Second guarantor Title N CEO
second_gurrantor_date Second guarantor Date N YYYY-MM-DD
business_per_sale What percentage of sales are business (%) Y 25
individual_per_sale What percentage of sales are Individuals (%) Y 75
customer_base_usa Ecommerce merchants - % of customer base USA Y 30
customer_base_ue Ecommerce merchants - % of customer base EU (Europe) Y 20
customer_base_la Ecommerce merchants - % of customer base LA (Latin America) Y 20
customer_base_asia Ecommerce merchants - % of customer base Asia Y 20
customer_base_othr Ecommerce merchants - % of customer base OTHER country Y 10
specify_customer_base_othr Ecommerce merchants - % of customer base OTHER country C If select customer base other country then need to specify
cardcharge_on_orderday CARDS ARE CHARGED ON THE Day Of Order N Other
cardcharge_on_other_specify CARDS ARE CHARGED ON THE Other C, If selct card are charged on other then need to specify
time_to_product_shipped When the product will shipped? C, If selct card are charged on other then need to specify 15 Days
deliver_digital_content Do you deliver digital content? N Yes or NO
list_of_url_login List all URLs C, If you deliver digital content google.com, facebook.com
deliver_phisical_product Do you deliver a physical product? N Yes or NO
who_ship_product Who will Ship The Product N
product_delivery_7days Product Delivery 7days Y 25%
product_delivery_8_14days Product Delivery in 8 to 14days Y 25%
product_delivery_15_30days Product Delivery 15 to 30 Days Y 25%
product_delivery_31days Product Delivery 31days Y 25%
require_deposit_for_future_delivery Deposit For Future Delivery N Yes Or NO
percent_of_sale_require Percent Of Sale N 10
flat_fee_require Flat Fee N 10
final_payment_due_before_fulfillment Final Payment Due Before Fulfillment N Yes Or No
number_of_day Number Of Day N
auto_negetive_billing_option Auto Negetive Billing Option N Yes Or No
product_guarantee_warranty Product Guarantee Warranty N Yes Or No
guarantee_warranty_is Guarantee Warranty Is N
refund_policy Refund Policy N Yes Or No
return_policy_display_written_available Return Policy Display Written Available N Yes Or No
explain_return_policy_display_written_available Explain Return Policy Display Written Available C, Required If Yes return policy written available
business_of_recurring_billing Business Of Recurring Billing N Yes Or No
business_of_recurring_billing_frequency Business Of Recurring Billing Frequency N 5
business_of_recurring_billing_frequency_specify Business Of Recurring Billing Frequency Specify C If yes then specify
card_payment_info_enter_into_system Card Payment Info Enter Into System N Yes Or No
card_payment_info_enter_into_system_specify Card Payment Info Enter Into System Specify C If select yes then need to specify card payment info enter into system
payment_info_enter_via_internet Payment Info Enter Via Internet N Yes Or No
payment_channel_encrypt_by_ssl Payment Channel Encrypt By Ssl Y Yes Or No
process_seasonally Process Seasonally N
processing_month Process Month N "jan","feb","nov"
highest_monthly_sale Highest monthly sale N "jan","feb","nov"
peak_month Peak Month N "jan","feb","nov"
business_require_special_licence Business Require Special Licence N Yes Or No
licence_type Licence Type N
own_product_inventory Own Product Inventory N Yes Or No
is_business_located_your_location Is Your Business Located Your Location? N Yes Or No
store_address Store Address N 777 Free school street
reseller_agreement Reseller agreement N Yes, No
product_stored_shipped_from Product Stored Shipped From Y Ohio
fulfillment_center_name Fulfillment Center Name N ABCD
fulfillment_contact_name Fulfillment Contact Name N John Paul
fulfillment_contact_phone Fulfillment Contact Phone N 1234567890
fulfillment_contact_email Fulfillment Contact Email N abcd@website.com
fulfillment_contact_address Fulfillment Contact Address N 777 Brockton Avenue
fulfillment_contact_city Fulfillment Contact City N Abington
fulfillment_contact_state Fulfillment Contact State N MA
fulfillment_contact_zip Fulfillment Contact Zip N 33606
method_of_delivery Method Of Delivery Y 1 for US Postal, 2 for Fedex, 3 for UPS, 4 for Courier, other
specify_other_method Specify Other Method C If you select other method then you need to specify
display_receipt_request Display Receipt Request N
trade_company_name Trade Company Name N Paul Com
trade_contact_name Trade Contact Name N John Paul
trade_contact_phone Trade Contact Phone N 1234567890
trade_contact_title Trade Contact Title N Mr
trade_contact_address Trade Contact Address N 777 Brockton Avenue
trade_contact_city Trade Contact City N Abington
trade_contact_state Trade Contact State N 1234567890
trade_contact_zip Trade Contact Zip code N 33606
pci_store_credit_card Is pci store credit card N Y: Yes, N: No
pci_third_party_detail_processor_detail Pci third party detail processor detail N
pci_third_party_detail_processor_version Pci third party detail processor version N
is_been_sanctioned_a_card_scheme_or_acquirer Is been sanctioned a card scheme or acquirer N Y: Yes, N: No
is_ever_defaulted_on_a_debt_or_obligation Is ever defaulted on a debt or obligation N Y: Yes, N: No
is_ever_been_terminated_by_an_acquirer_or_processor Is ever been terminated by an acquirer or processor N Y: Yes, N: No
is_ever_been_involved_in_a_bankruptcy_proceeding Is ever been involved in a bankruptcy proceeding N Y: Yes, N: No
explain_processing Explain Processing C, Required if Yes above any fields test
type Accepted Card Type Y MasterCard, Visa Required
AmericanExpress, Discover Optional
attributes Accepted Card attributes C

Discover Attribute 1 (mandatory) name - Acquired value - Yes or No Attribute 2 (Include if and only if Acquired = No) name - AccountNumber value - the account number associated with the card

AmericanExpress Attribute 1 (mandatory) name - AmexProgram values - ESA or OptBlue Attribute 2 (Include if and only if AmexProgram = ESA) name - AccountNumber value - the account number associated with the card Attribute 3 (Optionally included if AmexProgram = OptBlue. Defaults to No.) name - ReceiveOptBlueMarketing value - Yes or No

The table describes the MCC Name.

MCC Name MCC Code
Air Conditioning, heating and Plumbing Contractors 1711
Insulation, Masonry, plastering, Stonework and Tile Setting Contractors (Retail) 1740
Roof and Siding, Sheet Metal Work Contractors (Retail) 1761
Contractors, Special Trade - not elsewhere classified (Retail) 1799
Sanitation, Polishing, and Specialty Cleaning Preparations (Retail) 2842
Chemicals and Allied Products, not elsewhere classified (Retail) 5169
Miscellaneous Food Stores-Convenience Stores, Specialty Markets (Retail) 5499
Automotive Tire Stores (Retail) 5532
Automotive Parts, Accessories Stores (Retail) 5533
Floor Coverings Stores (Retail) 5713
Music Stores, Musical Instruments, Pianos, Sheet Music (Retail) 5733
Caterers (Retail) 5811
Eating Places, Restaurants (Retail) 5812
Bars, Cocktail Lounges, Drinking Places (Alcoholic Beverages) (Retail) 5813
Fast Food Restaurants (Retail) 5814
Package Stores, Beer, Wine, and Liquor (Retail) 5921
Miscellaneous and Specialty retail Stores (Retail) 5999
Lodging - Hotels, Motels, Resorts - not elsewhere classified (Retail) 7011
Counseling Services - Debt, Marriage, and Personal (Retail) 7277
Automotive Body Repair Shops (Retail) 7531
Motion Picture Theaters (Retail) 7832
Video Amusement Game Supplies (Retail) 7993
Amusement Parks, Carnivals, Circuses, Fortune Tellers (CNP) 7996
Recreation Services - not elsewhere classified (Retail) 7999
Doctors and Physicians - Not Elsewhere Classified (Regular doctors offices) 8011
Doctors and Physicians - Not Elsewhere Classified (CBD) 8011
Counseling Services - Debt, Marriage, and Personal (ECOM) 7277
Amusement Parks, Carnivals, Circuses, Fortune Tellers (Retail) 7996
Bars, Cocktail Lounges, Drinking Places (Alcoholic Beverages) (CNP) 5813
Automotive Tire Stores (CNP) 5532
Miscellaneous Food Stores-Convenience Stores, Specialty Markets (CNP) 5499
Insulation, Masonry, plastering, Stonework and Tile Setting Contractors (CNP) 1740
Lodging - Hotels, Motels, Resorts - not elsewhere classified (CNP) 7011
Motion Picture Theaters (CNP) 7832
Eating Places, Restaurants (CNP) 5812
Automotive Parts, Accessories Stores (CNP) 5533
Roof and Siding, Sheet Metal Work Contractors (CNP) 1761
Automotive Body Repair Shops (CNP) 7531
Package Stores, Beer, Wine, and Liquor (CNP) 5921
Fast Food Restaurants (CNP) 5814
Sanitation, Polishing, and Specialty Cleaning Preparations (CNP) 2842
Caterers (CNP) 5811
Contractors, Special Trade - not elsewhere classified (CNP) 1799
Music Stores, Musical Instruments, Pianos, Sheet Music (CNP) 5733
Floor Coverings Stores (CNP) 5713
Recreation Services - not elsewhere classified (CNP) 7999
Miscellaneous and Specialty retail Stores (CNP) 5999
Video Amusement Game Supplies (CNP) 7993
Chemicals and Allied Products, not elsewhere classified (CNP) 5169
Miscellaneous and Specialty Retail Shops (Retail) 5999
Miscellaneous and Specialty Retail Shops (CNP) 5999
Doctors and Physicians - Not Elsewhere Classified (Regular doctors offices) (CNP) 8011

The table describes the Source.

Source Details Source Code
Friend/ Colleague friend_colleague
Search Engine search_engine
Social Media social_media
Other other

HEADER PARAMETERS:

Content-Type: application/json

REQUEST BODY SCHEMA:

application/json

Response:

Response of the API Call is a JSON array. For Error,Two elements are returned. They are code and msg.For Successful transactions, three elements are returned. They are code, msg and application_id. Response code is always 00 for successful API call.

Example:


                                  $requestString='    {
    "username":"APP_USERNAME",
    "password":"APP_PASSWORD",
    "general": {
        "mcc_code":"6318",
        "source_code":"social_media",
        "source_msg":"",
        "country_code":"USA"
    },
    "bankDiscloser": {
        "principal_name":"Sunanda Roy",
        "principal_title":"CEO",
        "bank_disclousure_date":"2021-10-10"
    },
    "businessInfo": {
        "legal_name":"new tcb 22nd Feb",
        "irs_tax_name":"test",
        "street_number":"777",
        "address": "Brockton Avenue",
        "address_2":"",
        "state":"MA",
        "city":"Abington",
        "zip_code":"02351",
        "land_telephone":"4567891120",
        "land_telephone_iso2":"91",
        "ein_no": "123445589",
        "started_date": "2010-10-10",
        "state_filling":"CA",
        "business_type": "AutoRental",
        "is_contact_info_same_as_business_info":"Y",
        "contact_phone":"4567891120",
        "contact_phone_iso2":"91",
        "contact_email":"abcdef@website.com",
        "contact_name":"Subrata Roy",
        "contact_title":"Mr",
        "postal_code_extension":"1230"
    },
    "dbaInfo": {
        "chain_code":"03846S",
        "dba_name":"test dba 22nd Feb",
        "street_number":"700",
        "address":"Brockton Avenue",
        "address1":"",
        "city":"Abington",
        "state":"MA",
        "zip_code":"02351",
        "phone":"5555556666",
        "business_website":"tcbpay.com",
        "dba_business_email":"abcdf@business.com",
        "customer_service_no":"5555556666",
        "customer_service_no_iso2":"",
        "billing_descriptor":"tes*tDb*a",
        "add_terminals":"Y",
        "mail_monthly_merchant_to":"L",
        "ownership_type":"Trust"
    },
    "siteSurveyInfo": {
        "zone":"1",
        "location":"2",
        "approx_square_footage":"2000",
        "is_all_product_delivered_immediately":"No"
    },
    "bankAccount": {
        "is_dba":"Y",
        "dda_type":"Checking",
        "ach_type":"CommercialChecking",
        "routing_no":"021000021",
        "account_no":"123456789456123",
        "debit_account_merchant_dba_or_leagal":"Y",
        "batch_close_method":"TimeInitiated",
        "batch_close_time":"20:00:00",
        "check_for_duplicate_transactions":"Yes",
        "enable_commercial_card_bin_query":"No",
        "validate_bank_account":"Y"
    },
    "salesProfile": {
        "swipe_per":"0",
        "eco_per":"80",
        "moto_per":"20",
        "visa_mc_discover_monthly_volume":"5000",
        "visa_mc_discover_avg_ticket":"10000",
        "visa_mc_discover_high_ticket":"10000000",
        "visa_mc_discover_minimum_ticket":"1000",
        "amex_monthly_volume":"5000",
        "amex_avg_ticket":"10000",
        "amex_high_ticket":"1000",
        "amex_minimum_ticket":"1000",
        "card_charge_delay_id":"100"
    },
    "owners": [
        {
            "type":"BeneficialOwner1",
            "title":"Owner",
            "email":"abcdf@website.com",
            "ownership_per":"50",
            "first_name":"Subrata",
            "middle_initial":"",
            "last_name":"Roy",
            "date_of_birth":"2000-10-19",
            "street_number":"775",
            "address":"Brockton Avenue",
            "address1":"",
            "city":"Abington",
            "state":"MA",
            "zip_code":"02351",
            "home_telephone":"5555556666",
            "home_telephone_ext":"91",
            "fax_number":"",
            "country":"USA",
            "postal_code_extension":"",
            "driving_licance_issued_city":"",
            "driving_licance_issued_country":"",
            "driving_licance_date_issued":"2018-10-19",
            "driving_licance_expiration_date":"2028-10-19",
            "ssn":"999999999",
            "driving_licance_no":"786fg6587g",
            "driving_licance_state":"MA",
            "has_significant_managerial_control":1
        },
        {
            "type":"BeneficialOwner2",
            "title":"Co-Owner",
            "email":"12345@website.com",
            "ownership_per":"50",
            "first_name":"Subrata",
            "middle_initial":"",
            "last_name":"Roy",
            "date_of_birth":"2000-10-19",
            "street_number":"775",
            "address":"Brockton Avenue",
            "address1":"",
            "city":"Abington",
            "state":"MA",
            "zip_code":"02351",
            "home_telephone":"5555556666",
            "home_telephone_ext":"91",
            "fax_number":"",
            "country":"USA",
            "postal_code_extension":"",
            "driving_licance_issued_city":"",
            "driving_licance_issued_country":"",
            "driving_licance_date_issued":"2018-10-19",
            "driving_licance_expiration_date":"2028-10-19",
            "ssn":"999999999",
            "driving_licance_no":"786fg6587g",
            "driving_licance_state":"MA",
            "has_significant_managerial_control":1
        }
    ],
    "personalGuaranty": {
        "first_gurrantor_name":"Subrata Roy",
        "first_gurrantor_title":"MR",
        "first_gurrantor_date":"2021-10-07",
        "second_gurrantor_name":"Sanjay Roy",
        "second_gurrantor_title":"MR",
        "second_gurrantor_date":"2021-10-07"
    },
    "schedulea": {
        "is_next_day_funding_requested":"N",
        "exiting_ebt_item_no":"123456",
        "existing_amex_ac_no":"5649875465"
    },
    "questionnaire": {
        "business_per_sale":"60",
        "individual_per_sale":"40",

        "method_of_marketing":[
            "1","2","7"
        ],

        "customer_base_usa":"40",
        "customer_base_ue":"20",
        "customer_base_la":"20",
        "customer_base_asia":"10",
        "customer_base_othr":"10",
        "specify_customer_base_othr":"India",

        "cardcharge_on_orderday":"other",
        "cardcharge_on_other_specify":"other",
        "time_to_product_shipped":"30 Days",

        "deliver_digital_content":"Yes",
        "list_of_url_login":[
            "google.com",
            "facebook.com"
        ],

        "deliver_phisical_product":"No",
        "who_ship_product":"I dont know",

        "product_delivery_7days":"30",
        "product_delivery_8_14days":"20",
        "product_delivery_15_30days":"10",
        "product_delivery_31days":"40",

        "require_deposit_for_future_delivery":"No",
        "percent_of_sale_require":"10",
        "flat_fee_require":"10",
        "final_payment_due_before_fulfillment":"No",
        "number_of_day":"",

        "auto_negetive_billing_option":"No",

        "product_guarantee_warranty":"No",
        "guarantee_warranty_is":"",

        "refund_policy":"No",

        "return_policy_display_written_available":"No",
        "explain_return_policy_display_written_available":"",

        "business_of_recurring_billing":"No",
        "business_of_recurring_billing_frequency":"5",
        "business_of_recurring_billing_frequency_specify":"",

        "card_payment_info_enter_into_system":"No",
        "card_payment_info_enter_into_system_specify":"",

        "payment_info_enter_via_internet":"No",
        "payment_channel_encrypt_by_ssl":"No",

        "process_seasonally":"No",
        "processing_month":[
            "jan","feb","nov"
        ],

        "highest_monthly_sale":[
            "jan","feb","nov"
        ],

        "peak_month":[
            "jan","feb","nov"
        ],

        "business_require_special_licence":"No",
        "licence_type":"",

        "own_product_inventory":"No",
        "is_business_located_your_location":"No",
        "store_address":"Kolkata",
        "reseller_agreement":"No",

        "product_stored_shipped_from":"Kolkata",
        "fulfillment_center_name":"abc",
        "fulfillment_contact_name":"Sankar Roy",
        "fulfillment_contact_phone":"9999999999",
        "fulfillment_contact_email":"aabbccdd@mail.com",
        "fulfillment_contact_address":"Kolkata",
        "fulfillment_contact_city":"India",
        "fulfillment_contact_state":"WB",
        "fulfillment_contact_zip":"700131",

        "method_of_delivery":"2",
        "specify_other_method":"",
        "display_receipt_request":"",

        "trade_company_name":"SROY",
        "trade_contact_name":"ss",
        "trade_contact_phone":"879465130",
        "trade_contact_title":"Mr",
        "trade_contact_address":"7770 Brockton",
        "trade_contact_city":"Abington",
        "trade_contact_state":"MA",
        "trade_contact_zip":"84564"
    },
    "paymentsApplicationCompliance": {
        "pci_store_credit_card":"Y",
        "pci_third_party_detail_processor_detail":"",
        "pci_third_party_detail_processor_version":""
    },
    "processingHistory": {
        "is_been_sanctioned_a_card_scheme_or_acquirer":"N",
        "is_ever_defaulted_on_a_debt_or_obligation":"N",
        "is_ever_been_terminated_by_an_acquirer_or_processor":"N",
        "is_ever_been_involved_in_a_bankruptcy_proceeding":"Y",
        "explain_processing":"test"
    },
    "acceptedCard": [
        {
            "type": "MasterCard"
        },
        {
            "type": "Visa"
        },
        {
            "type": "AmericanExpress",
            "attributes": [
                {
                    "name": "AmexProgram",
                    "value": "ESA"
                },
                {
                    "name": "AccountNumber",
                    "value": "123456789"
                }
            ]
        }
    ]
}';

                  $headers = array( "Content-type: application/json" );
                  $serverUrl = 'https://app.tcbpay.com/api/onboarding';

                  $ch=curl_init();
                  curl_setopt($ch, CURLOPT_URL, $serverUrl);
                  curl_setopt($ch, CURLOPT_RETURNTRANSFER, 1);
                  curl_setopt($ch, CURLOPT_HTTPHEADER, $headers);
                  curl_setopt($ch, CURLOPT_POST, 1);
                  curl_setopt($ch, CURLOPT_POSTFIELDS, $requestString);
                  $result = curl_exec($ch);
                  curl_close($ch);



Sample Response :

{"response":{ "application_id": "XXXXXXXXXXXXXXXX", "msg": "Successfull", "code": "00" }


Success Code: 00
Success Message: Successfull

File Upload

This API will Upload Files.

URL To Call: https://app.tcbpay.com/api/onboardingFileUpload
Method of Form Submission: POST

The table describes the request parameters for File Upload.

Variable Name Description Required Expected Values
username Merchant App Username Y Merchant App Username
password Merchant App Password Y Merchant App Password
application_id The Application ID From Onbaording Y XXXXXXXXXXXXXX
file_url The URL of upload files Y https://app.tcbpay.com/assets/app_pdf/abcdefghijk.pdf
document_type Type of document need to upload Y DriverLicence, CorporateDocuments, BusinessUtilityBill

HEADER PARAMETERS:

Content-Type: application/json

REQUEST BODY SCHEMA:

application/json

Example:


                                  {
                  "username":"YOUR USERNAME",
                  "password":"YOUR PASSWORD",
                  "application_id":"XXXXXXXXXX",
                  "file_url":"https://app.tcbpay.com/assets/app_pdf/TCBPay_PayFac_Merchant_Application.pdf",
                  "document_type":"driverLicence"
                  }



Sample Response :

{"response":{ "msg": "success", "code": "00" }


Success Code: 00
Success Message: success

Submit Application

This API will Submit The Application.

URL To Call: https://app.tcbpay.com/api/onboardingSubmit
Method of Form Submission: POST

The table describes the request parameters to perform this API.

Variable Name Description Required Expected Values
username Merchant App Username Y Merchant App Username
password Merchant App Password Y Merchant App Password
application_id The Application ID From Onbaording Y XXXXXXXXXXXXXX

HEADER PARAMETERS:

Content-Type: application/json

REQUEST BODY SCHEMA:

application/json

Example:


                                  {
                    "username":"YOUR USERNAME",
                    "password":"YOUR PASSWORD",
                    "application_id":"XXXXXXXXXX"
                  }



Sample Response :

{"response":{ "msg": "Application Submitted successfully", "code": "00", "doc_url": "https://app.tcbpay.com/merchant_portal/download_view/1e438be7a8828fa5f6febeb024e64793" }


Success Code: 00
Success Message: Application Submitted successfully
Document URL: https://app.tcbpay.com/merchant_portal/download_view/1e438be7a8828fa5f6febeb024e64793

Status OF Application

This will Change Status OF Application.

URL To Call: https://app.tcbpay.com/api/onboardingStatus
Method of Form Submission: POST

The table describes the request parameters for this API.

Variable Name Description Required Expected Values
username Merchant App Username Y Merchant App Username
password Merchant App Password Y Merchant App Password
application_id The Application ID From Onbaording Y XXXXXXXXXXXXXX

HEADER PARAMETERS:

Content-Type: application/json

REQUEST BODY SCHEMA:

application/json

Example:


                                  {
                    "username":"YOUR USERNAME",
                    "password":"YOUR PASSWORD",
                    "application_id":"XXXXXXXXXX"
                  }



Sample Response :

{"response":{ "status_reason": null, "status_title": "Filled Up Forms" }


Success Code: 00
Success Message: Successfull

WooCommerce Plugin

Version 1.0

Requires WordPress Version : 5.0 or higher
Compatible up to : 5.2.3
Woocommerce plugin version : 3.6.3 higher
Compatible up to : 3.7.0

This plugin allows you to use TCB Payment gateway for your Woo-commerce site, as an additional payment options.

Installation:

There are two methods of it.
A. Place the unzipped plugin into wp-content/plugins folder inside your wordpress site
B. from Wordpress Admin go to Plugins – Add New. Click on Upload Plugin, browse the zip version of TCB Pay plugin folder.

Manage:

After successful installation of the plugin, you have to activate the TCBPay plugin from Plugins Installed Plugins.

Once the TCBPay plugin is activated, you can manage the plugin settings from Woo-commerce Settings Payments TCBPay.

Click on Manage. On the manage screen you can set the following values

Title : Name what you wish to appear on your cart page as payment option.
Description : If you wish to specify any note for the plugins for your customers.
Username : This is the username provided by TCBPay when you signed up for an account.
API Key : This is the API Key provided by TCBPay when you signed up for an account.

Keep the Enable test mode checked, if you want to run the Plugin in test environment.

ss ss

Download the wordpress plugin package as zip   Click here

PrestaShop Module

Version 1.0

Prestashop Version : 1.7.0 or higher
Compatible up to : 1.7.5

This plugin allows you to use TCB Pay payment gateway for your PrestaShop.

Installation:

Navigate to the Modules menu and click on the Module manager button. You would be redirected to the Modules management screen. Click on the Upload a module button to proceed with the installation. A new pop-up would appear. You may either drop the module's .zip file in that pop-up or use the select file link to browse for that module.

Manage:

A new pop-up with Module Installed! message would appear and that's it! Your module is installed now. You may click on the Configure button to edit the newly installed module's options

In the configure screen you can set the following values

Enabled: If Yes then this payment method appear in your cart page as payment option.
Test Mode: If Yes account turned into debug mode
Merchant Username : This is the username provided by Tcb pay when you signed up for an account.
API Key: This is the API Key provided by Tcb pay when you signed up for an account.
Credit Card Type: Choose card type from dropdown
Use CVV: Choose Yes to use CVV

magento magento

Download the PrestaShop extension package as zip.   Click here

Shopify Module

  1. Click here for instructions on how to set up Shopify and TCB Pay.
  2. Click here to watch an instructional video on how to sign up for Shopify through TCB Pay.
  3. Click here for instructions on how to integrate Shopify with your business.

Magento Module

Version 1.0

Magento Version : 2.0 or higher
Compatible up to : 2.1.*

This plugin allows you to use TCBPay payment gateway for your Magento, as an additional payment options.

Installation:

Create a folder name code under magento root directory/app. Place the un zipped module folder under this newly created code folder. Now run the following command from magento root derectory :

  • php bin/magento setup:upgrade
  • php bin/magento setup:static-content:deploy if store is in production mode
  • php bin/magento cache:clean

Manage:

After successful installation of the plugin, you have to enable and manage setting the TCBPay payment gateway from
STORESCONFIGURATIONSALESPayment MethodsTCBPay Payment Gateway


In the manage screen you can set the following values

Enabled: If Yes then this payment method appear in your cart page as payment option.
Title: Name what you wish to appear in your cart page as payment option.
Merchant Username : This is the username provided by Tcbpay when you signed up for an account.
API Key: This is the API Key provided by Tcbpay when you signed up for an account.

magento

Download the megento extension package as zip.   Click here

Opencart Module

Version 1.0.0

Opencart Version : 3.0 or higher
Compatible up to : 3.1.*

This plugin allows you to use TCBPay payment gateway for your Opencart, as an additional payment options.

Installation:

There are two methods of it.
A. Unzip the opencart plug-in folder there will be 3 folder admin,catalog,system then upload 3 folders inside the opencart project folder.
B. Login into opencart admin module then goto Extension Installer option – select the plug-in zip and upload it then goto Extensions option and select payment option from extension type we will find we will find TCB Pay and then install by clicking install button.

Manage:

After successful installation of the plugin, you have to enable and manage setting the TCBPay payment gateway from
Extensions ExtensionsPayment MethodsTCBPay Payment GatewayClick on Edit.


In the manage screen you can set the following values

Merchant Username : This is the username provided by Tcbpay when you signed up for an account.
API Key: This is the API Key provided by Tcbpay when you signed up for an account.
Credit Card Types: Select your accepted card.
Test Mode: If we select yes then we get sandbox if no then production.
Status: We must set it enable.

magento
magento

Download the opencart extension package as zip.   Click here

osCommerce Module

Version 1.0.0

Opencart Version : 2.3 or higher
Compatible up to : 2.3.*

This plugin allows you to use TCBPay payment gateway for your Opencart, as an additional payment options.

Installation:


1. Copy all new files with your catalog. It won't rewrite any of your files. Just copy & paste on top.
2. In the admin side of your web site go to Modules - Payment and install the new TCB Pay payment. Edit the payment put credentials and setup with your own settings.
3.Modify the following files as per the following instructions.
1.Installation Instructions:

A:


                                Find around line 139 in catalog/checkout_process.php file
                               $customer_notification = (SEND_EMAILS == 'true') ? '1' : '0';

Add Bellow Code above this "$customer_notification = (SEND_EMAILS == 'true') ? '1' : '0';" line: $order_comment = $order->info['comments']; if ($tcbpay_transaction_id) { $order_comment .= "\nTransaction Id: $tcbpay_transaction_id"; }

B:


                                Find bellow code around line 144 :
                                'comments' => $order->info['comments']
                                Replace With
                                'comments' => $order_comment



C:


                                Find  around line 36 in admin/modules.php:
                                while (list($key, $value) = each($HTTP_POST_VARS['configuration'])) {
                                Add The code bellow the line:
                                if (is_array($value)) $value = implode(',', $value);




D:


                                add the following code at end of the admin/includes/functions/general.php file.


                               function tep_cfg_pull_down_tcbpay_cctypes($cctypes, $key = '') {
                    $name = 'configuration[' . $key . '][]';

                    $cctypes_array = array(
                      array(
                        'id' => 'AE',
                        'text' => MODULE_PAYMENT_TCBPAY_TEXT_AMERICAN_EXPRESS
                      ), array(
                        'id' => 'VI',
                        'text' => MODULE_PAYMENT_TCBPAY_TEXT_VISA
                      ),  array(
                        'id' => 'MC',
                        'text' => MODULE_PAYMENT_TCBPAY_TEXT_MASTERCARD
                      ), array(
                        'id' => 'DI',
                        'text' => MODULE_PAYMENT_TCBPAY_TEXT_DISCOVER
                      ), array(
                        'id' => 'JCB',
                        'text' => MODULE_PAYMENT_TCBPAY_TEXT_JCB
                      ), array(
                        'id' => 'OT',
                        'text' => MODULE_PAYMENT_TCBPAY_TEXT_OTHER
                      )
                    );

                    return tep_draw_multi_select_menu($name, $cctypes_array, $cctypes);
                  }



E:



                                add the following code at end of the admin/includes/functions/general.php file.
                                function tep_draw_multi_select_menu($name, $values, $default = array(), $parameters = '', $required = false) {
                  global $HTTP_GET_VARS, $HTTP_POST_VARS;

                  $field = <select multiple name="' . tep_output_string($name) . '"';

                    if (tep_not_null($parameters)) $field .= ' ' . $parameters;

                    $field .= >
                    if (empty($default) && (isset($HTTP_GET_VARS[$name]) || isset($HTTP_POST_VARS[$name]))) {
                        if (isset($HTTP_GET_VARS[$name])) {
                        $default = $HTTP_GET_VARS[$name];
                     } elseif (isset($HTTP_POST_VARS[$name])) {
                     $default = $HTTP_POST_VARS[$name];
                      }
                    }
                    if (!is_array($default)) $default = explode(',', $default);

                    for ($i=0, $n=sizeof($values); $i<$n; $i++) {
                  $field .= <option value="' . tep_output_string($values[$i]['id']) . '"';
                  if (in_array($values[$i]['id'], $default)) {
                    $field .= ' selected="selected"';
                  }
                  $field .= > . tep_output_string($values[$i]['text'], array('"' => '"', '\'' => ''', '<' => '<', '>' => '>')) . <option>;
                 }
                  $field .= <select>;
                  if ($required == true) $field .= TEXT_FIELD_REQUIRED;

                  return $field;






Manage:

In the manage screen you can set the following values

Username : This is the username provided by Tcbpay when you signed up for an account.
API Key: This is the API Key provided by Tcbpay when you signed up for an account.
Credit Card Types: Select your accepted card.
Test Mode: If true TCB Test Pay Enable If false TCB test Pay disable.

magento

Download the osCommerce extension package as zip.   Click here

Zen Cart Module

Version 1.0.0

Zen Cart Version : 1.5 or higher
Compatible up to : 1.5.*

This plugin allows you to use TCBPay payment gateway for your Zen Cart, as an additional payment options.

Installation:


1. Copy all new files within your catalog. It won't rewrite any of your files. Just copy & paste on top.
2.Modify the following files as per the following instructions.
1.Installation Instructions:

A:


                                Find admin/includes/functions/general.php file

Add Bellow Code At The End function zen_cfg_pull_down_tcbpay_cctypes($cctypes, $key = '') { $name = 'configuration[' . $key . '][]'; $cctypes_array = array( array( 'id' => 'AE', 'text' => MODULE_PAYMENT_TCBPAY_TEXT_AMERICAN_EXPRESS ), array( 'id' => 'VI', 'text' => MODULE_PAYMENT_TCBPAY_TEXT_VISA ), array( 'id' => 'MC', 'text' => MODULE_PAYMENT_TCBPAY_TEXT_MASTERCARD ), array( 'id' => 'DI', 'text' => MODULE_PAYMENT_TCBPAY_TEXT_DISCOVER ), array( 'id' => 'JCB', 'text' => MODULE_PAYMENT_TCBPAY_TEXT_JCB ), array( 'id' => 'OT', 'text' => MODULE_PAYMENT_TCBPAY_TEXT_OTHER ) ); return zen_draw_multi_select_menu($name, $cctypes_array, $cctypes); }

B:


                                Find admin/includes/functions/html_output.php file

Add Bellow Code At The End function zen_draw_multi_select_menu($name, $values, $default = array(), $parameters = '', $required = false) { $field = '<select multiple rel="dropdown" name="'.zen_output_string($name).'"'; if (zen_not_null($parameters)) { $field .= ' ' . $parameters; } $field .= '>' . "\n"; if (empty($default) && isset($GLOBALS[$name])) { $default = $GLOBALS[$name]; } if (!is_array($default)) $default = explode(',', $default); foreach($default as $dval) { $default[] = trim($dval); } foreach ($values as $value) { $field .= '<option value="' . zen_output_string($value['id']) . '"'; if (in_array($value['id'], $default)) { $field .= ' selected="selected"'; } $field .= '>' . zen_output_string($value['text'], array('"' => '"', '\'' => ''', '<' => '<', '>' => '>')) . 'option>' . "\n"; } $field .= 'select>' . "\n"; if ($required == true) { $field .= TEXT_FIELD_REQUIRED; } return $field; }

3. In the admin side of your web site go to Modules - Payment and install the new TCB Pay payment. Edit the payment put credentials and setup with your own settings.

Manage:

In the manage screen you can set the following values

Username : This is the username provided by Tcbpay when you signed up for an account.
API Key: This is the API Key provided by Tcbpay when you signed up for an account.
Credit Card Types: Select your accepted card.
Test Mode: If true TCB Test Pay Enable If false TCB test Pay disable.

magento

Download the Zen Cart extension package as zip.   Click here

X-Cart Module

Version 1.0.0

X-Cart Version : 5.4.1.31 or higher
Compatible up to : 5.4.*

This plugin allows you to use TCBPay payment gateway for your X-Cart, as an additional payment options.

Installation:


1. Open X-Cart admin panel, And login with correct credential.
2.Please Click on Apps and then click on My Apps from left side menu.
3. Than click on Upload Addon from top right corner and then upload TCBPay module zip.
4. After successful upload click on Store Setup and then Pyement Method from left side menu.
5. Put credentials and setup with your own settings

Manage:

In the manage screen you can set the following values

Merchant Username : This is the username provided by Tcbpay when you signed up for an account.
API Key: This is the API Key provided by Tcbpay when you signed up for an account.
Credit Card Types: Select your accepted card.
Test Mode: If true TCB Test Pay Enable If false TCB test Pay disable.
Use CVV: If true CVV should Enable If false TCB Pay CVV disable.

X-Cart

Download the X-Cart extension package as tgz.   Click here

Android

Version 2.4.0

TCB Pay is a secure and simple way to process credit card transaction from your android phone. Just sign in with your gateway credentials and you can be processing payments in seconds.

iOS

Version 3.0.0

TCB Pay is a secure and simple way to process credit card transaction from your android phone. Just sign in with your gateway credentials and you can be processing payments in seconds.
